Used machines for sale
 Rinser bottle washers
Main brands:
Alcoa, Angelus, Arbras, Brabeer, Envasare, Holstein Kappert, Imarvil, IMSB, KHS, Montex, Omega Lavana, Rodopac, Zegla, Ziemann Liess
|
| Rinser bottle washers |
A rinser for bottles and jars is equipment used in the packaging industry to clean and rinse bottles or jars before filling them with products, such as beverages, food, chemical or pharmaceutical products. The main function of the rinser is to ensure that packaging is clean and free of residues before filling, contributing to the quality and safety of packaged products. Here are some details about the function and basic functioning of a rinser:
1. Rinser Function:
The main function of a bottle and jar rinser is to remove dirt, particles, dust, or any other residue that may be present on the packaging. This is essential to guarantee the integrity of the final product, prevent contamination and maintain hygiene standards on the filling line.
2. Main Components:
Bottle and jar rinsers can vary in design, but generally have the following main components:
Conveyor Belt: Moves the bottles or jars throughout the process.
Rinsing Stations: Where rinsing is carried out, often using nozzles or injectors of water or other cleaning liquid.
Control System: To operate and control the rinsing process.
3. Basic Operation:
The operating process of a rinser for bottles and jars generally follows the basic steps below:
Packaging Feeding: Empty bottles or jars are fed onto the rinser conveyor belt.
Positioning at Rinsing Stations: As packages advance along the conveyor belt, they are positioned at rinsing stations.
Rinsing: At rinsing stations, nozzles or injectors release water or another cleaning solution to rinse bottles or jars.
Drainage and Exit: After rinsing, the packages pass through a drainage area to remove excess liquid. Afterwards, the clean packaging is sent to the next stage of the process, such as filling the product.
4. Features and Advantages:
Efficient Cleaning: The rinser performs efficient cleaning of packaging, removing particles and dirt.
Versatility: Can be used with different types of packaging, such as glass bottles, plastic or jars.
Automatic Control: Many rinsers have automatic control systems to optimize the process.
Improvement in Product Quality: Contributes to the quality and safety of the final product, avoiding contamination.
The use of a rinser for bottles and jars is a common practice on production lines, especially in industries where hygiene and product quality are priorities. |
|
|
|
 |
Brand: Brabeer
Stainless steel filling machine with 2 nozzles for beer bottles.
Includes the rinsing, filling and corking process for liquids.
Manufacturer: Brabeer.
Approximate capacity: 200 bottles per hour.*
* depending on the bottle, product, etc.
... |
|
|
 |
Brand: Imarvil
Stainless steel washer bottles, use to sterilize the product packing container to be filled.
the liquid used to wash is alcohol.
Brand: Imarvil... |
|
|
 |
Brand: Envasare
Automatic rinser for bottles.
Manufacturer/brand: Envasare Máquinas.
Model: ENV-RNS - 12P.... |
|
|
 |
Brand: Zegla
Automatic rinser for bottles.
Manufacturer/brand: Zegla.
Year: 1996.... |
|
|
 |
Brand: Zegla
Balloon-type rinser washer for bottles.
Manufacturer/brand: Zegla.
Year: 2000.
For 500 ml, 1500 ml and 2000 ml bottles.... |
|
|
 |
Glass bottle rinser washer.
... |
|
|
 |
Brand: KHS, Mojonnier, Sabroe, Schulz, Ziemann Liess
Complete line plant for the production of beer and soft drinks.
Line composed of:
Bottle washer.
Manufacturer: Ziemann-Liess / KHS.
With 32 positions.
Year: 1994.
With tank system.
Linear rinser for bottles.
Nominal production... |
|
|
 |
Rinser Twister Type 6.85 Meters in length
Composed by dildo, bike pump 1 HP and 1 HP reducer... |
|
|
 |
Brand: IMSB, Rodopac
Components: Siemens
Stainless steel monobloc/tribloc filling machine.
Brand: IMSB.
Model: ERSB 1414/4.
Manufacturing Standard: MS.
Electrical Characteristics: 380 V.
Weight: 3.200 KG.
With 14 filling nozzles.
With 4 arms for threading caps.
With ... |
|
|
 |
Brand: KHS, Mojonnier, Posimec, Zegla
Complete line for the manufacture of carbonated beverages (with gas), including soft drinks, energy drinks, juices, alcoholic beverages.
Complete syrup with stainless steel tanks.
Carbon dioxide storage and pumping system for 8,000 kg.
Water... |
|
|
 |
Brand: Arbras
Rotary filling machine with 16 nozzles.
With bottle washer rinser.
Brand: Arbras.... |
|
|
 |
Brand: Zegla
Filler/Filler with 30 nozzles.
With threader and rinser.
Brand: Zegla.
Model: RZ30.
Year: 2000.
Approximate productivity: 4000 bottles/hour.
Isobaric filling machine for carbonates.... |
|
|
 |
Brand: Montex
Bottle washer.
Brand: Montex.
Capacity: 11,000 bottles per hour.
Voltage: 380 v.
Dimensions: 7000 mm x 2100 mm x 1500 mm.
Approximate weight: 300 kg.... |
|
|
 |
Brand: Omega Lavana
Large washer for bottles.
Brand: Omega Lavana.
Model: DM 22.
Type: 34/125.
Height: 4.2 m.... |
|
|
 |
Brand: Angelus, Grown Simplimatic, Pakmatic, Solbern
Complete line for can depalatization, rinser, filling, can rewriter, conveyor, chiller tunnel, baler, palletizer and strech wrapper.
More information get in touch.
Production: 42,000 u / h.
Depalletizer.
Brand: Grown Simplimatic.
Washe... |
|
|
 |
Brand: Arbras
Rotary filling machine rinser and capping bottle machine
Complete line for packaging.
Brand: Arbras.
With system of feeding bottles and lids.
Stainless steel.
Machine in acrinilo.... |
|
|
 |
Brand: Macmundi, Projepack, Vinox
VINOX filler/Capper monoblock.
Vxetgr model 12/4.
For non-carbonated mineral water PET 510 ml and 1.5 litres.
3000 unit production per hour reference 510 ml.
Vacuum and tunnel Projepack conjugate.
SLT model-400/RE (electric tunnel) to pac... |
|
|
 |
Brand: Holstein Kappert
Industrial Washing Machine.
Brand name: Holstein Kappert.
No. 301.
Type: 23/90.
Manufactured: 1976.... |
|
|
 |
Brand: Alcoa, Ata, Holstein Kappert, Rotix
Line for filling bottles of 180 ml to 1000 ml, and the washing machine can wash up to liter of brandy
01 washing machine bottles Holstein Kappert-P/16000 bottles/hour
1 Filler Kappert 60/10 Holstein P/9600 bottles/hour (Corker)
Rotix Labeller p... |
|
|
|
|
